The structure of customized poultry farm are flexible because different customers need different style. We help the customer design the structure to meet the individual requirements. We provide free design for you. Of course, we can follow your drawings to arrange.
The structure of customized poultry farm are flexible because different customers need different style. We help the customer design the structure to meet the individual requirements. We provide free design for you. Of course, we can follow your drawings to arrange. Our fireproof prefabricated wall battery prefab light steel hen house has many features. Low cost small prices, standardization, modular combination design, factory production, removable mobile, reusable, easy to stock restructuring, safe, environmental protection, beautiful and efficient light steel system integration house.
| Item | Specification |
| Material | Q235B, Q355B |
| Beam And Column | Q235, Q355 Welded H Section Steel |
| Purlin | C, Z-Shape Steel Purlin |
| Vertical Bracing | a) Round Steel b) Angle Iron c) Round Pipe |
| Horizontal Support | a) Round Steel b) Round Pipe |
| Tie Rod | Round Pipe |
| Angle Steel | Round Steel |
| Knuckle | Angle Iron |
| Door | a) Rolling Gate b) Sliding Door |
| Window | Pvc Steel Or Aluminum Alloy |
| Rain Spout | Round Pvc Pipe |
| Roof & Wall | a) Color-Coated Corrugated Steel Sheet |
| b) Rock Wool Sandwich Panels | |
| c) Eps Sandwich Panels | |
| d)Glass Wool Sandwich Panels | |
| Earthquake-Resistance | As Design |
| Wind Resistance Grade | As Design |
| Service Life | 50 Years |
1. Frame
High humidity and more ammonia can easily lead to some of the facilities corrosion. So we use galvanized H beam for columns and beams. We also use galvanized C beam for purlin. The galvanized frame can protect from being corroded thus can extend the life of the structure. Poultry shed in coastal city demand building have good wind resistance. We can design by the advanced software.
2. Panel
Depending on the climate in different regions, you can choose veneer or insulation composite panel. The plates have a variety of options colors. The board of tile can have a wide selection. Sandwich panels have EPS, glass fiber, rock wool. The panel can be heat insulation and prevent rust and corrosion. If you don't want to use the panel, you can use the wire mesh for wall. In hot or cold areas, we recommend to use composite panels, thermal insulation and heat insulation. Of course, the veneer price will be lower.
3. Height
Generally, if the poultry farm is free range farming, the height is 2m-3.5m. If it is cage farming, the height should be determined according to the number of cage layers.
4. Production time, installation time
About 3,000 square meters of the poultry shed, from design to sourcing to production finally ended is about a month.
5. Provide various types of ancillary farming equipment
